Alumina Ceramic Foam Filter

Alumina Ceramic Foam Filter is mainly designed to improve the quality of iron castings. The filter can effectively remove non-metallic inclusions including slag and dross from the molten metal stream.

Additionally, they aid in reducing turbulence in the gating system.

Alumina Ceramic Foam Filter outstanding thermal shock resistance and high strength properties were developed for superior performance in extreme iron or aluminium and copper based alloy foundry applications.

Alumina Ceramic Foam Filter Product Features
Precise sizes control during filter media sponge cutting to final sinter.
High strength with enough slurry and free from loose debris, no break and no filter slag.
Branded main raw material to ensure stable quality.
Good porosity and free from block during pouring molten metal.
Mature sintering technology to ensure high refractory and good thermal shock resistance.

Alumina Ceramic Foam Filter depending on the materials: alumina foam ceramic filters, silicon carbide ceramic foam filter, zirconia ceramic foam filter, and magnesium oxide foam ceramic filter.

Alumina Ceramic Foam Filter mainly for filtration of aluminium and aluminium alloys in foundries and cast houses. With their excellent resistance to attack and corrosion from molten aluminum, they can effectively remove inclusions, reduce trapped gas and provide laminar
flow, and then the filtered metal is significantly cleaner. Cleaner metal results in higher-quality castings, less scrap, and fewer inclusion defects, all of which contribute to bottom-line profit.

Alumina Ceramic Foam Filter (CFF-AL) Common Size
JINTAI CFF-AL is available in all common sizes: 7″, 9″, 12″, 15″, 17″, 20″, and 23″. AdTech offers the whole range of porosities from PPI 10 up to PPI 60 (PPI = pores per inch).

Alumina Ceramic Foam Filter is equipped with a gasket on the edges. The gasket assures the proper and tight position of the filter within the filter box. There are different types of gasket available, eg. ceramic fibre gasket etc. Also you can choose CFF-AL without gasket.

Alumina Ceramic Foam Filter

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
